Appendices
A - 42
NX-series Data Reference Manual (W525)
 Temperature Control Units
 System Units
NX Units Corresponding unit versions/versions
Model
Unit
version
Application with an NJ/NX/NY-series
Controller
*1
*1. Refer to the user’s manual for the EtherNet/IP Coupler Units for information on the unit versions of EtherNet/IP Units that
are compatible with EtherNet/IP Coupler Units.
Application with a CS/CJ/CP-series PLC
*2
*2. Refer to the user’s manual for the EtherNet/IP Coupler Units for information on the unit versions of CPU Units and Eth-
erNet/IP Units that are compatible with EtherNet/IP Coupler Units.
EtherNet/IP
Coupler
Unit
CPU Unit or
Industrial
PC
Sysmac
Studio
EtherNet/IP
Coupler
Unit
Sysmac
Studio
NX-IO Con-
figurator
NX-TC2405 Ver. 1.0 Ver. 1.2 Ver.1.14 Ver.1.21 Ver.1.2 Ver.1.21 Ver.1.11
NX-TC2406
NX-TC2407
NX-TC2408
NX-TC3405
NX-TC3406
NX-TC3407
NX-TC3408
NX Units Corresponding unit versions/versions
Model
Unit
version
Application with an NJ/NX/NY-series
Controller
*1
*1. Refer to the user’s manual for the EtherNet/IP Coupler Units for information on the unit versions of EtherNet/IP Units that
are compatible with EtherNet/IP Coupler Units.
Application with a CS/CJ/CP-series PLC
*2
*2. Refer to the user’s manual for the EtherNet/IP Coupler Units for information on the unit versions of CPU Units and
EtherNet/IP Units that are compatible with EtherNet/IP Coupler Units.
EtherNet/IP
Coupler
Unit
CPU Unit or
Industrial
PC
Sysmac
Studio
EtherNet/IP
Coupler
Unit
Sysmac
Studio
NX-IO Con-
figurator
*3
*3. For connection to an EtherNet/IP Coupler Unit with unit version 1.0, You can connect only to the peripheral USB port on
the EtherNet/IP Coupler Unit. You cannot connect with any other path. If you need to connect by another path, use an
EtherNet/IP Coupler Unit with unit version 1.2 or later.
NX-PD1000 Ver. 1.0 Ver. 1.2 Ver. 1.14 Ver. 1.19 Ver. 1.0 Ver. 1.10 Ver. 1.00
NX-PF0630
NX-PF0730
NX-PC0020
NX-PC0010
NX-PC0030
NX-TBX01

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
