Appendices
A - 46
NX-series Data Reference Manual (W525)
NX Unit Part 3
Function of EtherCAT Coupler Unit
Models of NX Units and unit versions
Temperature Control Units
CoE objects
*1
Reading/writing and saving Unit operation set-
tings and changing the write mode for the NX
Unit
*1. This function is supported by the NX-ECC203 with unit version 1.5 or later.
Ver.1.0
Restarting Restarting a specified NX Unit
*2
*2. If you use a CPU Unit, restart instructions that specify an NX Unit are supported by CPU Units with unit version 1.07 or
later. If you do not specify an NX Unit for the restart instruction, you can use version 1.05. Refer to the instructions refer-
ence manual for the connected CPU Unit or Industrial PC for details on the restart instructions for the NX Unit.
Ver.1.0
I/O checking Ver.1.0
Monitoring total power-ON time Ver.1.0
Restarting after
Clear All Mem-
ory operation
Restarting only the specified
NX Unit after performing the
Clear All Memory operation
for a specified NX Unit
Ver.1.0
Restarting after
transferring
Unit operation
settings
Restarting the NX Unit to
which the Unit operation set-
tings were transferred when
you transfer the settings to a
specified NX Unit
Ver.1.0
I/O refreshing
method
Time stamp refreshing
*3
• Input refreshing with input
changed time
• Output refreshing with
specified time stamp
*3. If you use a CPU Unit, the instructions for time stamp refreshing are supported by CPU Units with unit version 1.06 or
later. If you do not use instructions for time stamp refreshing, you can use version 1.05. Refer to the instructions refer-
ence manual for the connected CPU Unit or Industrial PC for details on the instructions for time stamp refreshing.
Not supported
Task period prioritized
refreshing
*4
*4. This method is supported only by the NX-ECC203.
Not supported
