A-3 Specific Values of NX Units for Perfor-
mance Calculation
A
A-3-4 Specific Values of NX Units Operate with Free-Run Refreshing
 Input Delay Time of NX Unit (Tnx-Indelay)
 Output Delay Time of NX Unit (Tnx-Outdelay)
NX Units
Tnx-Indelay
*1
*1. If only a definition is given in the above table, refer to the data of the NX Units in Section 1 Data List or the
manuals for the specific NX Units for the values of the items.
Remarks
Type Model
Digital Input Units Models support Free-Run
refreshing
ON/OFF
response time +
Input filter time
The ON/OFF response time
depends on the model of the Unit.
You can set the input filter time for
each Unit.
Digital Mixed I/O Units ON/OFF
response time +
Input filter time
This is applicable to the digital
inputs.
The ON/OFF response time
depends on the model of the Unit.
You can set the input filter time for
each Unit.
Analog Input Units Conversion time
× Number of
points
The conversion time and number of
points depend on the model of the
Unit.
Temperature Input
Units
Conversion time −
Incremental Encoder
Input Units
0 [μs] The value for pulse inputs and exter-
nal inputs.
SSI Input Units 0 [μs] −
Load Cell Input Unit NX-RS1201 0 [µs] −
Heater Burnout Detec-
tion Units
NX-HB3101
/-HB3201
Control period This is applicable to the CT inputs.
The value set for Out Control
Period of the time-proportional out-
put in the Unit operation settings of
the Heater Burnout Detection Unit.
Temperature Control
Units
All models 100 [ms] This is the value for measured value
and CT input.
NX Units
Tnx-Outdelay
*1
Remarks
Type Model
Digital Output Units Models support Free-Run
refreshing
ON/OFF
response time
The ON/OFF response time
depends on the model of the Unit.
Digital Mixed I/O Units ON/OFF
response time
This is applicable to the digital out-
puts.
The ON/OFF response time
depends on the model of the Unit.
Analog Output Units 0 [μs] −
Heater Burnout Detec-
tion Units
NX-HB3101
/-HB3201
Control period This is applicable to the control out-
puts. The value set for Out Control
Period of the time-proportional out-
put in the Unit operation settings of
the Heater Burnout Detection Unit.
