5 - 11

5 Installation and Wiring

NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)

5-3 Mounting Units

5-3-1 Installation in a Control Panel

 Controller Orientation

• Each Rack must be mounted in an upright position to provide proper cooling.

• Do not install a Rack in any of the following positions.

Mounting with the DIN Track on the Bottom

Mounting with the Rack Upside down Mounting with the DIN Track Installed Vertically

Mounting with the DIN Track on the Top

DIN Track
