5-4 Wiring
5
5-4-10 Wiring the NX1W-CIF01 Serial Communications Option Board
 Connection Example
Example: Twisted-pair cable connecting SD-SG, and RD-SG terminals when serial communications
mode is the host link.
Example: When using cables and devices that you used with CS/CJ/CP series.
Prepare a cable to convert the terminal block on the Serial Communications Option Board into the
D-sub9 for CS/CJ/CP series.
CIF01 side
Signal
Cable
Wiring example
Computer side
Signal
Pin
No.
Shell
Screwless
clamping
terminal
block (9 pin)
D-sub
9 pin (female)
SG0
RD
SD
ER
SG1
DR
RS
CS
SHLD
CD
RD
SD
ER
SG1
DR
RS
CS
CI
1
2
3
4
5
6
7
8
9
-
SG signal wires
Bundle the
SG wires
Aluminum
foil
XM2S-0911-E
CIF01 side
Signal
Cable
Wiring Example
Computer side
Signal
Pin
No.
Shell
Screwless
clamping
terminal
block (9 pin)
D-sub
9 pin (female)
SG0
RD
SD
ER
SG1
DR
RS
CS
SHLD
FG
SD
RD
ER
CS
5V
DR
ER
SG
1
2
3
4
5
6
7
8
9
-
