6 - 39
6 Troubleshooting
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
6-2 Troubleshooting
6
6-2-4 Error Descriptions
Event name Present Values of Retained Variables Restoration Error Event code 100F0000 hex
Meaning An error occurred in the software and the present values of retained variables could not be restored at startup. The val-
ues were initialized.
Source PLC Function Module Source details None Detection
timing
At power ON or
Controller reset
Error attributes Level Major fault Recovery Cycle the power
supply or reset
the Controller.
Log category System
Effects User program Stops. Operation
Stops
*1
.
The variables with a Retain attribute and memory for CJ-
series Units in the DM, EM, and Holding Areas were cor-
rupted. Normal user program execution or normal Unit
operation may not be possible. (NX1P2 CPU Unit)
The variables with a Retain attribute were corrupted. Nor-
mal user program execution or normal Unit operation may
not be possible. (NY-series Controllers)
*1. Refer to I/O Operation for Major Fault Level Controller Errors on page 6-8 for details.
System-defined
variables
Variable Data type Name
_RetainFail BOOL Retention Failure Flag
Cause and
correction
Assumed cause Correction Prevention
An error occurred in the software. Perform the following:
• Check the values of the retained
variables and the retained areas in
the memory used for CJ-series
Units and change them to the cor-
rect values. (NX1P2 CPU Unit)
• Check the values of the retained
variables and change them to the
correct values. (NY-series Control-
lers)
• If the system uses a Servomotor
with an absolute encoder, turn ON
the power supply, and then turn ON
the Servo and check the actual cur-
rent position of the axis.
None
Attached
information
None
Precautions/
Remarks
The following values are initialized.
• Retained variables (variables with a Retain attribute or variables in retained areas with AT specifications) (NX1P2
CPU Unit)
• Retained variables (variables with a Retain attribute) (NY-series Controllers)
• Retained areas in the memory used for CJ-series Units (NX1P2 CPU Unit)
• Absolute encoder home offset data
To Next Page
