6 Troubleshooting
6 - 54
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Event name NX Unit Serial Number Mismatch Event code 35930000 hex
Meaning There is a mounted NX Unit with a serial number different from that in the Unit configuration information registered in
the CPU Unit.
Source NX Bus Function Module Source details Master Detection
timing
At CPU Unit
power ON, at
Controller reset,
or at NX bus
restart
Error attributes Level Partial fault Recovery Cycle the power
supply to the
CPU Unit, reset
the Controller, or
restart the NX
bus.
Log category System
Effects User program Continues. Operation • For NX Units with this error, I/O communications will not
operate and message communications cannot be per-
formed.
• For NX Units without this error, I/O communications will
not operate, but message communications can be per-
formed.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
There is no mounted NX Unit with the
serial number that you set in the Unit
configuration information registered in
the CPU Unit.
To match the actual configuration with
the Unit configuration information,
match the serial number of the rele-
vant NX Unit . To match the Unit con-
figuration information with the actual
configuration, download the Unit con-
figuration information with the serial
number of the relevant NX Unit to the
CPU Unit.
Read the serial numbers of the actu-
ally mounted Units into a project in
the Sysmac Studio before you set the
Serial Number Verification setting to
verify the serial numbers.
Attached
information
Attached information 1: Unit number of the NX Unit where the error occurred
Attached information 2: Serial number in the Unit configuration information of the NX Unit where the error occurred
Precautions/
Remarks
None
Event name NX Bus Function Processing Error Event code 44440000 hex
Meaning A fatal error was detected in the NX Bus Function Module.
Source NX Bus Function Module Source details Master Detection
timing
Continuously
Error attributes Level Partial fault Recovery Cycle the power
supply to the
CPU Unit.
Log category System
Effects User program Continues. Operation I/O communications will not operate and message com-
munications cannot be performed.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
An error occurred in the software. Contact your OMRON representative. None
Attached
information
Attached information 1: System information
Attached information 2: System information
Attached information 3: System information
Attached information 4: System information
Precautions/
Remarks
None
To Next Page
