6 Troubleshooting
6 - 90
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
Event name User Program/Controller Configurations and Setup Down-
loaded
Event code 90050000 hex
Meaning The user program and the Controller configurations and setup were downloaded.
Source PLC Function Module Source details None Detection
timing
During user pro-
gram/Controller
configurations
and setup down-
load
Error attributes Level Information Recovery --- Log category Access
Effects User program Continues. Operation Operation starts according to the user program and the
Controller setup data that were downloaded.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The user program and the Controller
configurations and setup were down-
loaded.
--- ---
Attached
information
Attached Information 1: Connection method
1: Direct USB connection
2: Direct Ethernet connection
3: Remote USB connection or Ethernet hub connection
Attached Information 2: Connecting IP address, Connection through proxy: Proxy IP address
(When attached information 1 is 2 or 3)
Attached information 3: Device Output Hold Status
1: Retained.
2: Not retained.
Precautions/
Remarks
None
Event name Online Edits Transferred Event code 90070000 hex
Meaning The user program was edited online.
Source PLC Function Module Source details None Detection
timing
When transfer-
ring online edits
is started
Error attributes Level Information Recovery --- Log category Access
Effects User program Continues. Operation Operation is performed according to the changed user
program.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The user program was edited online
and the edits were transferred to the
Controller.
--- ---
Attached
information
Attached Information 1: Connection method
1: Direct USB connection
2: Direct Ethernet connection
3: Remote USB connection or Ethernet hub connection
Attached Information 2: Connecting IP address, Connection through proxy: Proxy IP address
(When attached information 1 is 2 or 3)
Precautions/
Remarks
None
