1 - 7
1 Introduction to NX-series Controllers
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
1-1 The NX-series Controllers
1
1-1-2 Introduction to the System Configurations
You can use the following Support Software to set up, monitor, and debug an NX-series Controller.
• Sysmac Studio
The Sysmac Studio is the main Support Software that you use for an NX-series Controller. On it, you
can set up the Controller configurations, parameters, and programs, and you can debug and simulate
operation.
• Other Support Software
The following Support Software is also included in the Sysmac Studio Software Package Standard
Edition.
Support Software
Configuration software Application
Sysmac Studio
The Sysmac Studio is used for sequence control, motion control, and all other
operations except those described below.
Network Configurator
The Network Configurator is used for tag data links on EtherNet/IP ports.
*1
*1. If the NJ/NX-series Controller is a target device, you may also use Sysmac Studio version 1.10 or higher. Use
the Network Configurator if a CS/CJ-series PLC operates as the originator device.
CX-Integrator
The CX-Integrator is used for remote I/O communications with a CJ-series Devi-
ceNet Unit or CJ-series CompoNet Master Unit.
CX-Protocol
The CX-Protocol is used for protocol macros with the CJ-series Serial Communi-
cations Units.
CX-Designer The CX-Designer is used to create screens for NS-series PTs.
To Next Page
