Omron NX1P2 series User Manual

3 Configuration Units
3 - 14
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
c) NX1P2-9024DT
The appearance of the terminal block is the same as a).
d) NX1P2-9024DT1
The appearance of the terminal block is the same as a).
Symbol Terminal name Description Reference
C0 (0V) Common terminal Connected to the 0-V side of the I/O
power supply.
Output Specifications on page
3-15
00 to 09 Output terminals NPN (sinking) type output
NC NC Do not connect anything. ---
Symbol Terminal name Description Reference
C0 (+V) Common terminal Connected to the 24-V side of the I/O
power supply.
Output Specifications on page
3-15
0V0 0 V terminal Supplies 0 V for the internal circuits
for driving.
00 to 09 Output terminals PNP (sourcing) type output with the
load short-circuit protection function
NC NC Do not connect anything. ---
NC
NC
NC
NC
NC
NC
NC
NC08
NC09
06
07
04
05
02
03
00
01
C0
(0V)
NC NC
NC
NC
NC
NC
NC
NC
NC
NC08
NC09
06
07
04
05
02
03
00
010V0
NC
C0
(+V)

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
