4-13
4-2 Function Mode
4
Functions
•The frequency reference and reversibility depend on whether "16" (AT) is allocated to a multi-
function input, and depend on the combination of A005 and A006, as shown below.
If the frequency reference is "reversible", the motor runs in the reverse direction when "main
frequency reference + auxiliary frequency reference" is less than zero, even if the FW (Forward)
terminal is ON. Also, note that the motor may run in the reverse direction, resulting in prolonged
acceleration time or other phenomena, if the voltage fluctuates around 0 V even with the FE
terminal not connected.
A006 FE selection
00: FE only
01: Auxiliary frequency reference of FV and FI
(not reversible)
02: Auxiliary frequency reference of FV and FI
(reversible)
03: FE disabled
03 
Related functions A005, A006, C001 to C008
Parameter No. Function name Data Default setting Unit
A006 A005
AT
terminal
Main frequency reference
Auxiliary frequency
reference
(FE-FC terminal)
Reversibility
With AT
allocated to a
multi-function
input
00, 03
00
OFF FV-FC terminal Disabled
Not
reversible
ON FI-FC terminal Disabled
01
OFF FV-FC terminal Disabled
ON FE-FC terminal Disabled Reversible
01
00
(Example 1)
OFF FV-FC terminal Enabled
Not
reversible
ON FI-FC terminal Enabled
01
OFF FV-FC terminal Enabled
ON FE-FC terminal Disabled Reversible
02
00
(Example 2)
OFF FV-FC terminal Enabled
Reversible
ON FI-FC terminal Enabled
01
OFF FV-FC terminal Enabled
ON FE-FC terminal Disabled
With AT NOT
allocated to a
multi-function
input
00 FE-FC terminal Disabled Reversible
01 
Addition of the FV-FC and
FI-FC terminals
Enabled
Not
reversible
02 
Addition of the FV-FC and
FI-FC terminals
Enabled Reversible
03 
Addition of the FV-FC and
FI-FC terminals
Disabled
Not
reversible
