7-26
7-3 Options
7
Specifications
TYPE
1
Resistor only
One units
2
Resistor only
Two units in
parallel
3
Resistor only
Two units in series
4
Resistor only
Three units in
parallel
5
Resistor only
Two parallel units
connected in
series to two other
parallel units
6
Three resistors in
series
Two units in
parallel
P/+2
Inverter
Resistor
RB
R
P/+2
Inverter
RB
RR
P/+2
Inverter
RB
R
R
P/+2
Inverter
RB
RRR
P/+2
Inverter
RB
RR
RR
P/+2
Inverter
RB
R
R
R
R
R
R
