7-27
7-3 Options
7
Specifications
7
One braking unit
Three resistors in
parallel
8
One braking unit
Two resistors in
parallel connected
in series to two
other parallel units
9
One braking unit
Three resistors in
parallel connected
in series to two
other parallel units
10
One braking unit
Four resistors in
parallel connected
in series to two
other parallel units
TYPE
P/+2
Inverter
PRB
Braking unit
(Resistor mounted
externally)
N/-
N
Voltage
detection
RRR
P/+2
Inverter
PRB
N/-
N
R
R
R
R
Voltage
detection
P/+2
Inverter
PRB
N/-
N
R
R
R
R
R
R
Voltage
detection
P/+2
Inverter
PRB
Braking unit
(Resistor mounted externally)
N/-
N
RRRR
RRRR
Voltage
detection
