7-41
7-3 Options
7
Specifications
Specifications
Power
supply
Model
Applicable
Inverter capacity
(kw)
External dimensions (mm)
Weight
(kg)
A C D E H H1 X Y
3-phase
200 V AC
3G3AX-AL2025 0.2 to 1.5 130 82 60 40 150 92 50 67 2.8
3G3AX-AL2055 2.2, 3.7 140 98 60 40 150 92 50 75 4.0
3G3AX-AL2110 5.5, 7.5 160 103 70 55 170 106 60 80 5.0
3G3AX-AL2220 11, 15 180 113 75 55 190 138 90 90 10.0
3G3AX-AL2330 18.5, 22 180 113 85 60 230 138 125 90 11.0
3G3AX-AL2500 30, 37 260 113 85 60 290 200 100 90 19.0
3G3AX-AL2750 45, 55 260 144 110 80 290 200 125 112 25.0
3-phase
400 V AC
3G3AX-AL4025 0.4 to 1.5 130 82 60 40 150 92 50 67 2.7
3G3AX-AL4055 2.2, 3.7 130 98 60 40 150 92 50 75 4.0
3G3AX-AL4110 5.5, 7.5 160 116 75 55 170 106 60 98 6.0
3G3AX-AL4220 11, 15 180 103 75 55 190 138 100 80 10.0
3G3AX-AL4330 18.5, 22 180 123 85 60 230 138 100 100 11.5
3G3AX-AL4500 30, 37 260 113 85 60 290 200 100 90 19.0
3G3AX-AL4750 45, 55 260 146 110 80 290 205 125 112 25.0
