2-20
2-2 Wiring
2
Design
*1. When the cable is connected without using the crimp terminal (bare wires), use the square washer included
with the product.
Note: The cable size is based on the HIV cable (75°C heat resistance).
400-V class
0.4
3G3RX-
A4004
1.25 1.25 1.25 M4 1.25-4
1.2
(max.1.8)
5 A
0.75
3G3RX-
A4007
1.25 1.25 1.25 M4 1.25-4
1.2
(max.1.8)
5 A
1.5
3G3RX-
A4015
22 2M42-4
1.2
(max.1.8)
10 A
2.2
3G3RX-
A4022
22 2M42-4
1.2
(max.1.8)
10 A
3.7
3G3RX-
A4037
22 2M42-4
1.2
(max.1.8)
15 A
5.5
3G3RX-
A4055
3.5 3.5 3.5 M5 R2-5
2.4
(max. 4.0)
30 A
7.5
3G3RX-
A4075
3.5 3.5 3.5 M5 3.5-5
2.4
(max. 4.0)
30 A
11
3G3RX-
A4110
5.5 5.5 5.5 M6 R5.5-6
4.5
(max. 4.4)
50 A
15
3G3RX-
A4150
88 8M68-6
4.5
(max. 4.9)
60 A
18.5
3G3RX-
A4185
14 14 14 M6 14-6
4.5
(max. 4.9)
60 A
22
3G3RX-
A4220
14 14 14 M6 14-6
4.5
(max. 4.9)
75 A
30
3G3RX-
A4300
22 22 - M6 22-6
4.5
(max. 4.9)
100 A
37
3G3RX-
A4370
38 22  M8
*1
38-8
8.1
(max. 20.0)
100 A
45
3G3RX-
A4450
38 22  M8
*1
38-8
8.1
(max. 20.0)
150 A
55
3G3RX-
A4550
60 30  M8
*1
R60-8
8.1
(max. 20.0)
175 A
75
3G3RX-
A4750
100
(38 × 2)
38  M10
*1
100-10
20.0
(max. 22.0)
225 A
90
3G3RX-
A4900
100
(38 × 2)
38  M10
*1
100-10
20.0
(max. 22.0)
225 A
110
3G3RX-
A411K
150
(60 × 2)
60  M10
*1
150-10
20.0
(max. 35.0)
350 A
132
3G3RX-
A413K
80 × 280  M10
*1
80-10
20.0
(max. 35.0)
350 A
Motor
output
(kW)
Applicable
Inverter
model
Power cable
(mm
2
)
R, S, T, U, V,
W, +1, P/+2,
N/-
Ground
cable
(mm
2
)
External
braking resistor
between +1
and RB (mm
2
)
Terminal
screw
size
Crimp
terminal
Tightening
torque
N•m
Applicable
device
Earth leakage
breaker (ELB)
