Omron SYSMAC CP Series Instruction & Reference Manual

2-125
2 Instructions
CP1E CPU Unit Instructions Reference Manual(W483)
Data Movement Instructions
2
COLL
COLL
Applicable Program Areas
Operands
Bs: Source Base Address
Of: Offset
The offset can be any value from 0000 to FFFF (0 to 65,535 decimal).
Note Bs and Bs+Of must be in the same data area.
 Operand Specifications
Flags
Instruction Mnemonic Variations
Function
code
Function
DATA COLLECT COLL @COLL 081
Transfers the source word (calculated by adding
an offset value to the base address) to the desti-
nation word.
Symbol
COLL
Area Step program areas Subroutines Interrupt tasks
Usage OK OK OK
Operand Description Data type Size
Bs Source base address WORD 1
Of Offset WORD 1
D Destination word WORD 1
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
Bs
OK OK OK OK OK OK OK OK OK
---
--- --- ---Of OK
D ---
Name Label Operation
Error Flag P_ER OFF
Equals Flag P_EQ • ON if the source data is 0000.
• OFF in all other cases.
Negative Flag P_N • ON if the leftmost bit of the source data is 1.
• OFF in all other cases
COLL(081)
Bs
Of
D
Bs: Source base address
Of: Offset
D: Destination word
15 0
Bs
Bs+Of
