Omron SYSMAC CP Series Instruction & Reference Manual

2-119
2 Instructions
CP1E CPU Unit Instructions Reference Manual(W483)
Data Movement Instructions
2
BSET
BSET
Applicable Program Areas
Operands
St: Starting Word
Specifies the first word in the destination range.
E: End Word
Specifies the last word in the destination range.
Note St and E must be in the same data area.
 Operand Specifications
Flags
Instruction Mnemonic Variations
Function
code
Function
BLOCK SET BSET @BSET 071
Copies the same word to a range of consecutive
words.
Symbol
BSET
Area Step program areas Subroutines Interrupt tasks
Usage OK OK OK
Operand Description Data type Size
S Source word WORD 1
St Starting word WORD Variable
E End word WORD Variable
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
S
OK OK OK OK OK OK OK OK OK
OK
--- --- ---
St, E ---
Name Label Operation
Error Flag P_ER • ON if St is greater than E.
• OFF in all other cases.
BSET(071)
S
St
E
S: Source word
St: Starting word
E: End word
15
to
0
St
E
