Omron SYSMAC CP Series Instruction & Reference Manual

2-77
2 Instructions
CP1E CPU Unit Instructions Reference Manual(W483)
Timer and Counter Instructions
2
TIML/TIMLX
TIML/TIMLX
Applicable Program Areas
Operands
 Operand Specifications
Flags
Instruction Mnemonic Variations
Function
code
Function
LONG TIMER
TIML --- 542
TIML(542)/TIMLX(553) operates a decrementing
timer with units of 0.1s.
TIMLX --- 553
Symbol
TIML TIMLX
BCD Binary
Area Step program areas Subroutines Interrupt tasks
Usage OK OK Not allowed
Operand Description
Data type
Size
TIML TIMLX
D1 Completion Flag WORD UINT 1
D2 PV word DWORD UDINT 2
S SV word DWORD UDINT 2
D1: Completion Flag
D2: PV Word
S: SV Word
The PV and SV can range from #00000000
to #99999999 for TIML(542) and &00000000
to &4294967294 (decimal) or #00000000 to
#FFFFFFFF (hexadecimal) for TIMLX(553).
Note S, S+1, D2 and D2+1 must be in the same
data area.
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
D1,D2
OK OK OK OK
--- ---
OK OK OK
---
--- --- ---
SOKOK OK
Name Label Operation
Error Flag P_ER • ON if in BCD mode and D2 does not contained BCD data.
• ON if in BCD mode and S does not contained BCD data.
• OFF in all other cases.
TIML(542)
D1
D2
S
D1: Completion Flag
D2: PV word
S: SV word
TIMLX(553)
D1
D2
S
D1: Completion Flag
D2: PV word
S: SV word
15
D1
0
Completion Flag
Do not use.
D2D2+1
D2
D2+1 is the leftmost 4 digits,
D2 is the rightmost 4 digits
SS+1
S
S+1 is the leftmost 4 digits,
S is the rightmost 4 digits
