2 Instructions
2-66
CP1E CPU Unit Instructions Reference Manual(W483)
TIM/TIMX
Applicable Program Areas
Operands
N: Timer Number
The timer number must be between 0000 and 0255 (decimal).
S: Set Value (100-ms Units)
TIM (BCD): #0000 to #9999.
TIMX (Binary): &0 to &65535 (decimal) or #0000 to #FFFF (hex).
 Operand Specifications
Flags
Instruction Mnemonic Variations
Function
code
Function
HUNDRED-MS TIMER TIM/TIMX --- 550
TIM or TIMX(550) operates a decrementing timer
with units of 0.1-s.
Symbol
TIM TIMX
BCD Binary
Area Step program areas Subroutines Interrupt tasks
Usage OK OK Not allowed
Operand Description
Data type
Size
TIM TIMX
N Timer Number TIMER TIMER 1
S Set Value WORD UINT 1
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
N --- --- --- ---
OK
--- --- --- --- ---
--- --- ---
S OKOKOKOK OKOK OK OK OK
Name Label Operation
Error Flag P_ER • ON if in BCD mode and S does not contain BCD data.
• OFF in all other cases.
TIM
N
S
S: Set value
N:Timer number
TIMX(550)
N
S
S: Set value
N: Timer number
