1 Summary of Instructions

1-2

CP1E CPU Unit Instructions Reference Manual(W483)

1-1 Summary of Instructions

There are 200 types of instructions can be used by CP1E.

The following table lists the instructions by function. Refer to the reference pages for the

detail of each instruction.

Instrucion

Type

Instruction Mnemonic

FUN

No.

Function Page

Sequence

Input Instruc-

tions

LOAD LD

Indicates a logical start and creates an ON/OFF execution condition based on

the ON/OFF status of the specified operand bit.

2-7

@LD

%LD

!LD

!@LD

!%LD

LOAD NOT LD NOT

Indicates a logical start and creates an ON/OFF execution condition based on

the reverse of the ON/OFF status of the specified operand bit.

2-7

@LD NOT

%LD NOT

!LD NOT

!@LD NOT

!%LD NOT

AND AND

Takes a logical AND of the status of the specified operand bit and the current

execution condition.

2-9

@AND

%AND

!AND

!@AND

!%AND

AND NOT AND NOT

Reverses the status of the specified operand bit and takes a logical AND with

the current execution condition.

2-9

@AND NOT

%AND NOT

!AND NOT

!@AND NOT

!%AND NOT

OR OR

Takes a logical OR of the ON/OFF status of the specified operand bit and the

current execution condition.

2-11

@OR

%OR

!OR

!@OR

!%OR

OR NOT OR NOT

Reverses the status of the specified bit and takes a logical OR with the current

execution condition.

2-11

@OR NOT

%OR NOT

!OR NOT

!@OR NOT

!%OR NOT

AND LOAD AND LD

Takes a logical AND between logic blocks. 2-13

OR LOAD OR LD

Takes a logical OR between logic blocks. 2-13

NOT NOT 520 Reverses the execution condition. 2-16

CONDITION ON UP 521 UP(521) turns ON the execution condition for one cycle when the execution

condition goes from OFF to ON.

2-17

CONDITION OFF DOWN 522 DOWN(522) turns ON the execution condition for one cycle when the execution

condition goes from ON to OFF.

2-17
