2 Instructions
2-398
CP1E CPU Unit Instructions Reference Manual(W483)
Other Instructions
STC/CLC
Applicable Program Areas
Flags
Function
 STC
When the execution condition is ON, STC(040) turns ON the Carry Flag (CY). Although STC(040) turns
the Carry Flag ON, the flag will be turned ON/OFF by the execution of subsequent instructions which
affect the Carry Flag.
ROL(027) and ROR(028) make use of the Carry Flag in their rotation shift operations.
 CLC
When the execution condition is ON, CLC(040) turns OFF the Carry Flag (CY). Although CLC(040)
turns the Carry Flag OFF, the flag will be turned ON/OFF by the execution of subsequent instructions
which affect the Carry Flag.
+C(402), +CL(403), +BC(406), +BCL(407), -C(412), -CL(413), -BC(416), and -BCL(417) make use of
the Carry Flag in their addition operations. Use CLC(041) just before any of these instructions to pre-
vent any influence from other preceding instructions.
ROL(027) and ROR(028) make use of the Carry Flag in their rotation shift operations.
Hint
The +(400), +L(401), +B(404), +BL(405), -(410), -L(411), -B(414), and -BL(415) instructions do no
include the Carry Flag in their addition and subtraction operations. In general, use these instructions
when performing addition or subtraction.
Instruction Mnemonic Variations
Function
code
Function
SET CARRY STC @STC 040 Sets the Carry Flag (CY).
CLEAR CARRY CLC @CLC 041 Turns OFF the Carry Flag (CY).
Symbol
STC CLC
Area Step program areas Subroutines Interrupt tasks
Usage OK OK OK
Operand Description
Data type
STC CLC
Carry Flag P_CY ON OFF
STC(040)
CLC(041)
