Omron SYSMAC CP Series Instruction & Reference Manual

2-185
2 Instructions
CP1E CPU Unit Instructions Reference Manual(W483)
Conversion Instructions
2
BIN/BINL
Conversion Instructions
BIN/BINL
Applicable Program Areas
Operands
 Operand Specifications
Flags
Instruction Mnemonic Variations
Function
code
Function
BCD TO BINARY BIN @BIN 023 Converts BCD data to binary data.
DOUBLE BCD TO DOUBLE
BINARY
BINL @BINL 058
Converts 8-digit BCD data to 8-digit hexadecimal
(32-bit binary) data.
Symbol
BIN BINL
Area Step program areas Subroutines Interrupt tasks
Usage OK OK OK
Operand Description
Data type Size
BIN BINL BIN BINL
S
BIN: Source word
BINL: First source word
WORD DWORD 1 2
R
BIN: Results word
BINL: First result word
UINT UDINT 1 2
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
S,R OKOKOKOKOKOKOK OK OK --- --- --- ---
Name Label
Operation
BIN BINL
Error Flag P_ER • ON if the content of S is not BCD.
• OFF in all other cases.
• ON if the contents of S+1, S are not BCD.
• OFF in all other cases.
Equals Flag P_EQ • ON if the result is 0000.
• OFF in all other cases.
• ON if the result is 0.
• OFF in all other cases.
Negative Flag P_N OFF OFF
S: Source word
R: Result word
BIN(023)
S
R
S: First source word
R: First result word
BINL(058)
S
R
