Omron SYSMAC CP Series Instruction & Reference Manual

2 Instructions
2-366
CP1E CPU Unit Instructions Reference Manual(W483)
• Converting 8 digits
C: Control Data
The value of C indicates the number of digits of source data and the logic for the Input and Output
Units, as shown in the following table. (The logic refers to the transistor output’s NPN or PNP logic.)
D: System Word
Specifies a work word used by the instruction. This word cannot be used in any other application.
 Operand Specifications
Flags
Function
7SEG(214) reads the source data, converts it to 7-segment display data, and outputs that data (as left-
most 4 digits D0 to D3, rightmost 4 digits D0 to D3, latch output signals LE0 to LE3) to the 7-segment
display connected to the output indicated by O. The value of C indicates the number of digits of source
data (either 4-digit or 8-digit) and the logic for the Input and Output Units.
7SEG(214) displays the 4-digit or 8-digit data in 12 cycles, and then starts over and continues display-
ing the data.
The One Round Flag (bit 08 of O when converting 4 digits, bit 12 of O when converting 8 digits) is
turned ON for one cycle in every 12 cycles after 7SEG(214) has turned ON each of the latch output sig-
nals.
Source data Display’s data input logic Display’s latch input logic C
4 digits (S) Same as Output Unit Same as Output Unit 0000
Different from Output Unit 0001
Different from Output Unit Same as Output Unit 0002
Different from Output Unit 0003
8 digits (S, S+1) Same as Output Unit Same as Output Unit 0004
Different from Output Unit 0005
Different from Output Unit Same as Output Unit 0006
Different from Output Unit 0007
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
S, O OKOKOKOKOKOKOK OK OK ---
--- --- ---C --- --- --- --- --- --- --- --- --- OK
D OKOKOKOKOKOKOK OK OK ---
Name Label Operation
Error Flag P_ER OFF
0123456789101112131415
O
D0
D1
D2
D3
LE3
LE2
LE1
LE0
D0
D1
D2
D3
Leftmost 4-digit data output
Rightmost 4-digit data output
Latch outputs
One Round Flag
D
15 0
System word
(Cannot be accessed b
y the user.)
