Omron SYSMAC CP Series Instruction & Reference Manual

Appendices
A-4
CP1E CPU Unit Instructions Reference Manual(W483)
D
E
F
H
I
J
K
L
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
DATE CLOCK
ADJUST-
MENT
735 @DATE --- --- 2-385
DI DISABLE
INTER-
RUPTS
693 @DI --- --- 2-306
DIFD DIFFEREN-
TIATE
DOWN
014 --- --- !DIFD 2-27
DIFU DIFFEREN-
TIATE UP
013 --- --- !DIFU 2-25
DIST SINGLE
WORD DIS-
TRIBUTE
080 @DIST --- --- 2-123
DMPX DATA
ENCODER
077 @DMPX --- --- 2-196
DOWN CONDI-
TION OFF
522 --- --- --- 2-17
DSW DIGITAL
SWITCH
INPUT
210 --- --- --- 2-357
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
EI ENABLE
INTER-
RUPTS
694 --- --- --- 2-307
END END 001 --- --- --- 2-38
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
FAL FAILURE
ALARM
006 @FAL --- --- 2-387
FALS SEVERE
FAILURE
ALARM
007 --- --- --- 2-393
FCS FRAME
CHECK-
SUM
180 @FCS --- --- 2-255
FIX FLOATING
TO 16-BIT
450 @FIX --- --- 2-233
FIXL FLOATING
TO 32-BIT
451 @FIXL --- --- 2-233
FLT 16-BIT TO
FLOATING
452 @FLT --- --- 2-235
FLTL 32-BIT TO
FLOATING
453 @FLTL --- --- 2-235
FOR --- 512 --- --- --- 2-56
FSTR FLOATING-
POINT TO
ASCII
448 @FSTR --- --- 2-244
FVAL ASCII TO
FLOATING-
POINT
449 @FVAL --- --- 2-249
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
HEX ASCII TO
HEX
162 @HEX --- --- 2-205
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
INI MODE
CONTROL
880 @INI --- --- 2-308
IORF I/O
REFRESH
097 @IORF --- --- 2-352
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
JME JUMP END 005 --- --- --- 2-53
JMP JUMP 004 --- --- --- 2-53
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
KEEP KEEP 011 --- --- !KEEP 2-21
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
LD LOAD --- @LD %LD !LD 2-7
LD=DT LOAD DATE
EQUAL
341 --- --- --- 2-91
LD =S LOAD
SIGNED
EQUAL
302 --- --- --- 2-88
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
