CP1E CPU Unit Instructions Reference Manual(W483)
Alphabetical List of Instructions by Mnemonic
App
P
R
OR= OR EQUAL 300 --- --- --- 2-88
OR=DT OR DATE
EQUAL
341 --- --- --- 2-91
OR=F OR
FLOATING
EQUAL
329 --- --- --- 2-241
OR=L OR
DOUBLE
EQUAL
301 --- --- --- 2-88
OR=S OR SIGNED
EQUAL
302 --- --- --- 2-88
OR=SL OR DOU-
BLE
SIGNED
EQUAL
303 --- --- --- 2-88
OR> OR
GREATER
THAN
320 --- --- --- 2-88
OR>= OR
GREATER
THAN OR
EQUAL
325 --- --- --- 2-88
OR>=
DT
OR DATE
GREATER
THAN OR
EQUAL
346 --- --- --- 2-91
OR>=F OR
FLOATING
GREATER
THAN OR
EQUAL
334 --- --- --- 2-241
OR>=L OR
DOUBLE
GREATER
THAN OR
EQUAL
326 --- --- --- 2-88
OR>=S OR SIGNED
GREATER
THAN OR
EQUAL
327 --- --- --- 2-88
OR>=
SL
OR DBL
SIGNED
GREATER
THAN OR
EQUAL
328 --- --- --- 2-88
OR>DT OR DATE
GREATER
THAN
345 --- --- --- 2-91
OR>F OR FLOAT-
ING
GREATER
THAN
333 --- --- --- 2-241
OR>L OR
DOUBLE
GREATER
THAN
321 --- --- --- 2-88
OR>S OR SIGNED
GREATER
THAN
322 --- --- --- 2-88
OR>SL OR
DOUBLE
SIGNED
GREATER
THAN
323 --- --- --- 2-88
ORW LOGICAL
OR
035 @ORW --- --- 2-212
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
ORWL DOUBLE
LOGICAL
OR
611 @ORWL --- --- 2-212
OUT OUTPUT --- --- --- !OUT 2-18
OUT
NOT
OUTPUT
NOT
--- --- --- !OUT
NOT
2-18
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
PIDAT PID CON-
TROL
WITHAUTO-
TUNING
191 --- --- --- 2-257
PLS2 PULSE
OUTPUT
887 @PLS2 --- --- 2-325
PRV HIGH-
SPEED-
COUNTER
PV READ
881 @PRV --- --- 2-311
PULS SET
PULSES
886 @PULS --- --- 2-323
PWM PULSE
WITH VARI-
ABLEDUTY
FACTOR
891 @PWM --- --- 2-339
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
RET SUBROU-
TINE
RETURN
093 --- --- --- 2-295
ROL ROTATE
LEFT
027 @ROL --- --- 2-135
ROR ROTATE
RIGHT
028 @ROR --- --- 2-137
RSET RESET --- @RSET %RSET !RSET 2-29
RSTA MULTIPLE
BIT RESET
531 @RSTA --- --- 2-31
RSTB SINGLE BIT
RESET
533 @RSTB --- !RSTB 2-33
RXD RECEIVE 235 @RXD --- --- 2-374
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
