Omron Sysmac NX-PD1000 User Manual

Terminal Blocks
There are two models of screwless clamping terminal blocks: NX-TB£££2 and NX-TB£££1. Each
model has three types of terminal blocks: 8-terminal type, 12-terminal type, and 16-terminal type. Use
the 16-terminal type for the Shield Connection Unit.

NX-TBC162
(B)
(C)
(A)
(D)
B1
B2
B3
B4
B5
B6
B7
B8
A1
A2
A3
A4
A5
A6
A7
A8

NX-TBA161
(B)
(C)
(A)
B1
B2
B3
B4
B5
B6
B7
B8
A1
A2
A3
A4
A5
A6
A7
A8
3 Part Names and Functions
3-10
NX-series System Units User's Manual (W523)
