Let-
ter
Name Function
(A) Terminal number indi-
cations
Terminal numbers for which A and B indicate the column, and 1 to 8 indicate
the line are displayed.
The terminal number is a combination of column and line, i.e. A1 to A8 and
B1 to B8.
(B) Release holes Insert a flat-blade screwdriver into these holes to connect and remove the
wires.
(C) Terminal holes The wires are inserted into these holes.
(D) Ground terminal mark
This mark indicates the ground terminals. It is only on the NX-TBC££2.
The NX-TB£££2 and NX-TB£££1 Terminal Blocks have dif
ferent terminal current capacities.
The former has 10 A and the latter has 4 A.
To differentiate between the two models of terminal blocks, use the terminal number column indica-
tions. The terminal block with white letters on a dark background is the NX-TB£££2.
You can mount either terminal block to the Shield Connection Unit.
Additional Information
The Shield Connection Unit is only compatible with the 16-terminal type. You cannot use a ter-
minal block with a different number of terminals.

Applicable Terminal Blocks for Each Unit Model
The following indicates the terminal blocks that are applicable to each Unit.
Unit model num-
ber
Terminal block
Model
Number of termi-
nals
Ground terminal
mark
Current capacity
NX-TBX01 NX-TBA161 16 Not provided 4 A
NX-TBC162 Provided 10 A
Additional Information
Refer to A-4 List of Screwless Clamping Terminal Block Models on page
A-27 for information
on the models of terminal blocks.
3 Part Names and Functions
3-11
NX-series System Units User's Manual (W523)
3-2 Names of Shield Connection Unit Parts
3
3-2-1 Screwless Clamping Terminal Block Type
