100
Section 5 Communications Commands
RFID System
Operation Manual
Section 5
Communications
Example 1
The following example fills 6 bytes (0006H) of memory starting from address 0030H with 0101H for a
Data Carrier in which the same data as the address is written.
Example 2
The following example fills 5 bytes (0005H) of memory starting from address 0030H with 1234H for a
Data Carrier in which the same data as the address is written.
06
DF
30
H1/2
00
211 4
2
2
CR
01
4
01
No. of write
bytes
Specified data
Terminator
Command code
Write area start address
Data code
specifica-
tion
R/W Head No.
Command
Response
Command code
DF
00
22
2
*CR
Terminator
End code
30
31
2F
32
33
35
36
34
002FH
0030H
0031H
0032H
0033H
0034H
0035H
0036H
Before Writing
01
01
2F
01
01
01
36
01
002FH
0030H
0031H
0032H
0033H
0034H
0035H
0036H
After Writing
05
DF
30
H1/2
00
211 4
2
2
CR
12
4
34
No. of write
bytes
Specified data
Terminator
Command code
Write area start address
Data code
specifica-
tion
R/W Head No.
*
Command
Response
DF
00
22
2
*CR
Command code
TerminatorEnd code
30
31
2F
32
33
35
36
34
002FH
0030H
0031H
0032H
0033H
0034H
0035H
0036H
Before Writing
12
34
2F
12
34
35
36
12
002FH
0030H
0031H
0032H
0033H
0034H
0035H
0036H
After Writing
