Section 5 Host Device Commands
RFID System
Operation Manual
Section 5
Communications
CONTROLLER CONTROL (CC)
CONTROLLER CONTROL is used to manipulate user I/O.
■ 1:1 Communications
Process code Always “00”.
OUT1/OUT2 control 0: No operation
1: Turn ON output
2: Turn OFF output
End code Indicates the results of command execution.
00: Normal end
Refer to End Codes for more information.
p.135
Input status The current input status. First character: IN1 or TRG1, Second character: IN2 or TRG2
0: OFF
1: ON
Output status The output input status after execution. First character: OUT1, Second character: OUT2
0: OFF
1: ON
Command
Command code
CC
00
xx
2
2
*CR
Terminator
1
Process code
2
OUT1
control
1
OUT2
control
Response
CC
00
xx
2
2
*CR
2
2
xx
2
Command code
End code
Input status
Output status
Terminator

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
