Omron V600 Series User Manual

131
RFID System
Operation Manual
Section 5 Host Device Commands
Section 5
Communications
■ 1:N Communications
Baud rate setting Sets the baud rate.
0: 1,200 bps
1: 2,400 bps
2: 4,800 bps
3: 9,600 bps
4: 19,200 bps
5: 38,400 bps
Default setting: 2,400 bps
Data length setting Sets the data length.
7: 7 bits
8: 8 bits
Default setting: 7 bits
Parity check setting Sets the parity check method.
0: No parity
1: Odd parity
2: Even parity
Default setting: Even parity
Stop bit setting Sets the number of stop bits.
1: 1 bit
2: 2 bits
Default setting: 2 bits
End code Indicates the results of command execution.
00: Normal end
Refer to End Codes for more information.
p.135
Command
Command code
TR
xx
21
2
*CR
Terminator
xx
Baud
rate
setting
1
Data
length
setting
1
Parity
check
setting
1
Stop bit
setting
2
xx
FCS
3
Controller No.
x
@ x
Response
Command code
TR
00
22
2
*CR
Terminator
End code
2
xx
FCS
3
Controller No.
x
@ x

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
