130
Section 5 Host Device Commands
RFID System
Operation Manual
Section 5
Communications
COMMUNICATIONS CONDITIONS SETTING (TR)
TR sets conditions for serial communications. After modifying a setting it is necessary to restart the ID
Controller or execute the ABORT command (XZ) to enable operating with the modified setting.
Setting communications conditions with this command is enable only when internal settings are enabled (i.e., when
SW3 pin 1 is ON).
1:1 Communications
Baud rate setting Sets the baud rate.
0: 1,200 bps
1: 2,400 bps
2: 4,800 bps
3: 9,600 bps
4: 19,200 bps
5: 38,400 bps
Default setting: 2,400 bps
Data length setting Sets the data length.
7: 7 bits
8: 8 bits
Default setting: 7 bits
Parity check setting Sets the parity check method.
0: No parity
1: Odd parity
2: Even parity
Default setting: Even parity
Stop bit setting Sets the number of stop bits.
1: 1 bit
2: 2 bits
Default setting: 2 bits
End code Indicates the results of command execution.
00: Normal end
Refer to End Codes for more information.
p.135
Command
Command code
TR
xx
21
2
*CR
Terminator
xx
Baud
rate
setting
1
Data
length
setting
1
Parity
check
setting
1
Stop bit
setting
Response
Command code
TR
00
22
2
*CR
Terminator
End code
