18
Section 1 System Configuration
RFID System
Operation Manual
Section 1
Product Overview
1:N Connections with RS-422/RS485 Host Device Connection
The host device is connected via RS-422 or RS-485 and then other ID Controllers are connected via
RS-422/RS-485.
ID Controller
V600-CA5D01/CA5D02
RS-422/RS-485
Read/Write Head
Data Carrier Pallet, etc.
RS-422/RS-485 RS-422/RS-485 RS-422/RS-485
Data Carrier Pallet, etc.
Programmable Controller (PLC)
Computer
