RFID System
Operation Manual
Section 1 System Configuration
Section 1
Product Overview
1:N Connections with RS-232C Host Device Connection
The host device is connected via RS-232C and then other ID Controllers are connected via RS-422/
RS-485.
ID Controller
V600-CA5D01/CA5D02
RS-232C
Read/Write Head
Data Carrier Pallet, etc.
RS-422/RS-485 RS-422/RS-485 RS-422/RS-485
Data Carrier Pallet, etc.
Programmable Controller (PLC)
Computer

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
