Omron V600 Series User Manual

83
RFID System
Operation Manual
Section 5 Communications Commands
Section 5
Communications
■ 1:N Communications
Data code specification Specifies the type of code in which to send the read data in the response.
A: ASCII
H: Hexadecimal
R/W Head No. Specifies the Read/Write Head with which to communicate.
1: Read/Write Head 1
2: Read/Write Head 2
Read area start address Specifies the first address from which to read data from the Data Carrier as a four-digit hexadeci-
mal number.
Specifiable range: 0000H to FFFFH
No. of read bytes Specifies the number of bytes of data to read from the Data Carrier as a two-digit hexadecimal
number. Up to 256 bytes can be read with one command.
• ASCII specification: 256 bytes (256 characters)
• Hexadecimal code specification: 256 bytes (512 characters)
Specifiable range: 00H to FFH (The maximum of 256 bytes will be read if 00H is specified.)
End code Indicates the results of command execution. An end code of 00 is returned for a normal end.
Refer to End Codes for more information.
p.135
Read data The data read from Data Carrier memory. The number of characters will be the same as the num-
ber of read bytes for ASCII data and twice the number of read bytes for hexadecimal data.
xx
xx
A/H
1/2 x
3142
xx
1
x
2
FCS
2
*CR
Terminator
RD
2
Command
code
Controller No.
x
@x
Data
code
specifi-
cation
Read area start address
No. of read
bytes
R/W Head No.
Command
Response
Command
code
RD
x
00
xx
22 n
2
*CR
Terminator
Read dataEnd code
x x
2
FCS
x
3
Controller No.
x
@x

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
