89
RFID System
Operation Manual
Section 5 Communications Commands
Section 5
Communications
EXPANSION WRITE (XW)
For EXPANSION WRITE, the ID Controller writes up to 2 KB to Data Carrier memory data by dividing
the data into frames. If there is no Data Carrier in the communications area, an error response with an
error code of 72 (Data Carrier missing) will be returned.
The host device cannot send commands to the ID Controller until all response frames have been
returned. (Excluding the AA command and XZ command.)
1:1 Communications
Frame 1
Frame 2 and Later Frames
Data code specification Specifies the type of code in which the write data is being sent.
A: ASCII
H: Hexadecimal
R/W Head No. Specifies the Read/Write Head with which to communicate.
1: Read/Write Head 1
2: Read/Write Head 2
Write area start address Specifies the first address to which to write data to the Data Carrier as a four-digit hexadecimal
number.
Specifiable range: 0000H to FFFFH
Write data The data to write to Data Carrier memory. Up to 2,048 bytes can be written with one command.
ASCII: 2,048 bytes (2,048 characters)
Hexadecimal: 2,048 bytes (4,096 characters)
Delimiter CR: Indicates the end of the frame when there is another frame.
Terminator *CR: Indicates the end of the frame when there is not another frame.
End code Indicates the results of command execution. An end code of 00 is returned for a normal end.
Refer to End Codes for more information.
p.135
Command
xx
Command code
xW
xx
A/H 1/2
xx
211 4
Write data
1 or 2
*CR
Terminator
n
xx
Data
code
specifi-
cation
Write area start address
R/W Head No.
xx
xxxx
Write data
1 or 2
*CR
Terminator
n
xx
Response
Command code
xW
00
22
2
*CR
Terminator
End code
