Onkyo TX-SR3100

61
Setup
2. Speaker
 3. Distance
Set the distance from each speaker to the listening position.
 Front Left (Default Value: 12.0 ft/3.60 m)
Center (Default Value: 12.0 ft/3.60 m)
Front Right (Default Value: 12.0 ft/3.60 m)
Height Left (Default Value: 9.0 ft/2.70 m)
Height Right (Default Value: 9.0 ft/2.70 m)
Surround Right (Default Value: 7.0 ft/2.10 m)
Surround Left (Default Value: 7.0 ft/2.10 m)
Subwoofer (Default Value: 12.0 ft/3.60 m)
• Default values vary depending on the regions.
• The unit of distance can be changed by pressing the MODE button on the
remote controller. When the unit is set as feet, you can set between 0.1 ft
and 30.0 ft in increments of 0.1 ft. When the unit is set as meters, you can set
between 0.03 m and 9.00 m in increments of 0.03 m.
 4. Level Calibration
Adjust the volume level of each speaker.
 Front Left (Default Value: 0.0 dB)
Center (Default Value: 0.0 dB)
Front Right (Default Value: 0.0 dB)
Height Left (Default Value: 0.0 dB)
Height Right (Default Value: 0.0 dB)
Surround Right (Default Value: 0.0 dB)
Surround Left (Default Value: 0.0 dB)
Subwoofer (Default Value: 0.0 dB)
Select a value between "-12.0 dB" and "+12.0 dB" ("-15.0 dB" and "+12.0 dB"
for Subwoofer) (in 0.5 dB increments). A test tone will be output each time you
change the value. Select the desired level.
