Onkyo TX-SR653E - Specifications; Amplifier and General Specifications; Video and Tuner Specifications; Input;Output and Other Jacks

85
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Other Jacks
Specifications and features are subject to change without
notice.
Power Output
2 channel driven: 125 W + 125 W
(6 Ω, 1 kHz, DIN)
Dynamic Power 225 W + 225 W (3 Ω, Front)
175 W + 175 W (4 Ω, Front)
105 W + 105 W (8 Ω, Front)
THD (Total Harmonic
Distortion) 0.08 % (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and
Impedance 200 mV/47 kΩ (LINE)
Output Level and
Impedance 200 mV/470 Ω (REC OUT)
Frequency Response 10 Hz–100 kHz/+1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
SN Ratio 106 dB (LINEIHF-A)
Speaker Impedance 4 Ω–
Input Sensitivity/Output
Level and Impedance 1 Vp-p/75 Ω (Component and S-Video Y)
0.7 Vp-p/75 Ω (Component Pb/Cb, Pr/Cr)
0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)
Component Video
Frequency Response 5 Hz–50 MHz
Tuning Frequency Range 87.5 MHz–108.0 MHz
Usable Sensitivity Stereo: 22.2 dBf (75 Ω IHF)
Mono: 15.2 dBf (75 Ω IHF)
S/N Ratio Stereo: 67 dB (IHF-A)
Mono: 73 dB (IHF-A)
THD Stereo: 0.5 % (1 kHz)
Mono: 0.3 % (1 kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 40 dB (1kHz)
Tuning Frequency Range 530 kHz–1611 kHz
Usable Sensitivity 300 µV
S/N Ratio 40 dB
THD 0.70%
Power Supply AC 230-240 V, 50 Hz
Power Consumption 630 W
Stand-by Power
Consumption 0.2 W
Dimensions (W x H x D) 435 W x 174 H x 377 D mm
Weight 11.1 kg
Component Video Input 1,2,3
S-Video Compatible Jack
Input DVD, VIDEO1, VIDEO2, VIDEO3,
VIDEO4
A/V Input DVD, VIDEO1, VIDEO2, VIDEO3,
VIDEO4
Component Video
Output OUT
S-Video Compatible Jack
Output MONITOR OUT, VIDEO1, VIDEO2
A/V Output MONITOR OUT, VIDEO1, VIDEO2
Digital Inputs Optical: 4
Coaxial: 2
Analog Inputs DVD(MULTICHANNEL), VIDEO1,
VIDEO2, VIDEO3, VIDEO4, TAPE, CD
Multichannel Inputs 6
Digital Outputs Optical: 1
Analog Outputs TAPE, VIDEO1, VIDEO2, ZONE2
Subwoofer Pre Outputs 1
Speaker Outputs 9
Phones 1
IR Input 1
12V Trigger Out 1
