OP4200 HARDWARE - CASSETTES
TYPICAL APPLICATIONS
The following diagrams provide an example of a typical application using the OP4230-1.
Signal
Conditionning
VDC+
GND
-
+
15 mA max
Analog In
OP4230-1 Analog Output
Client Side
Figure 15: Figure 2: Typical application diagram
