34 OPAL-RT Technologies OP4200 User Manual
OP4200 Hardware Specifications
OP4200 General Specifications
OP4250-1 SPECIFICATIONS
Product name OP4250-1 (32 opto-isolated digital inputs)
Number of channels 32 digital inputs
Isolation Optical isolator
Connection mode Anode and cathode available on connector
Input current 3.6 mA, current limiting diode
Reverse voltage protection Schottky diode
Maximum reverse voltage protection 30 Volts
Detection threshold Separate Schmitt Trigger
Voltage range 4 to 50 Vdc
Delay Low-to-High 110 ns
Delay High-to-Low 60 ns
Rise/Fall times 6 ns/6 ns
Form factor Mezzanine Type B
Dimensions 6.60 cm x 12.50 cm (2.6” x 4.92”)
I/O connector 80-pin high speed header to carrier (internal connection
DB37F (external connection)
Operating temperature 10 to 40 ºC (50 to 104ºF)
Storage temperature -55 to 85ºC (-67 to 185ºF)
Relative humidity 10 to 90%, non condensing
Maximum altitude 2,000 m (6562 ft.)
