OP4200 User Manual OPAL-RT Technologies 35
OP4200 Hardware Specifications
OP4200 General Specifications
OP4260-1 SPECIFICATIONS
Product name OP4260-1 (32 digital outputs - push-pull)
Number of channels 32 digital outputs
2 banks of 16, fully isolated and independant of each other
Isolation Galvanic isolator
Output Protection 50 mA resettable fuse
Protection thresholds Over voltage: 30V ±5%
Under voltage protection 5V ±2.5%
Reverse voltage: maximum 30 V.
Output Voltage range 5 to 30 Vdc max
Output configuration Push-pull, tri-state output
Delay Low-to-High ≤ 65ns @ 25°C for 30 V
≤ 200ns @ 25°C for 5 V
Delay High-to-Low ≤ 65ns @ 25°C for 30 V
≤ 200ns @ 25°C for 5 V
Rise/Fall times <= 15 ns
Form factor Mezzanine Type B
Dimensions 6.60 cm x 12.50 cm (2.6” x 4.92”)
I/O connector 80-pin high speed header to carrier
Operating temperature 10 to 40 ºC (50 to 104ºF)
Storage temperature -55 to 85ºC (-67 to 185ºF)
Relative humidity 10 to 90%, non condensing
Maximum altitude 2,000 m (6562 ft.)
