32 OPAL-RT Technologies OP4200 User Manual
OP4200 Hardware Specifications
OP4200 General Specifications
OP4240-1 SPECIFICATIONS
Product Name: OP4240-1
Number of channels: OP4240-1: 16 differential
Resolution: 16 bits
Max. Sampling Frequency: 500 kS/s
Min Conversion / Acquisition Time: 2.5 μs per channel
ADC Type: 8 x Dual ADC with 10 MBit/s Serial Output Transfer
Nominal Input Ranges (V)
Positive Full Scale Negative Full Scale
+120.0 -120.0
+100.0 -100.0
+80.0 -80.0
+60.0 -60.0
+40.0 -40.0
+20.0 (hardware default value) -20.0
Calibration Calibration factors are stored in on-board non-volatile memory (flash memory).
This memory is not accessible for calibration.
Recommended warm-up time: 5 min.
Calibration interval: as required
Dimensions: 6.60 cm x 12.50 cm (2.6” x 4.92”)
I/O connector: 80-pin high speed header to carrier
Environmental
Operating temperature: 10 to 40 °C
Storage temperature: -55 to 85 °C
Relative humidity: 10 to 90%, non condensing
Maximum altitude: 2,000 m
