30 OPAL-RT Technologies OP4200 User Manual
OP4200 Hardware Specifications
OP4200 General Specifications
OP4200 HARDWARE SPECIFICATIONS
OP4200 GENERAL SPECIFICATIONS
Product name OP4200
CPU ARM® Processor dual-core Cortex A9 1GHz (1000MHz optional)
Memory 16 GB SD card, 1024 MB SRAM
O/S Linux-based real-time operating system
FPGA Xilinx Zynq®XC7Z030, Kintex™-7 FPGA, 125K LUT
I/O lines 128 lines, routed to cassette conditioning modules
Communication ports 2 GTX SFP connectors, up to 5Gbps
I/O connectors DB37F
RS232
CAN
I/O cassette slots 4 slots for I/O cassettes
Power supply External Power supply, 100-240VAC, 50-60Hz, 60VA
24V ± 10% @ max 2.5A
Dimensions 25 x 22x 28 cm (9.8’’ x 8.7’’ x 11.2’’) HxWxD
Weight 4.54kg (10 lbs)
Operating temperature 10 to 35 ºC (50 to 95ºF)
Storage temperature -55 to 85ºC (-67 to 185ºF)
Maximum rated ambient
temperature
40Cº (104ºF)
Relative humidity 10 to 90% non-condensing
Maximum altitude 2000 m (6562 ft.)
