OP4200 User Manual OPAL-RT Technologies 33
OP4200 Hardware Specifications
OP4200 General Specifications
OP4242-1 SPECIFICATIONS
Product name OP4242 analog to digital converter (16 analog inputs - 2 MSPS)
Part number 410-0072
Number of channels 16
Resolution 16 bits
Input impedance
1 M
Ω
Max. Sampling Frequency 2 MSPS
Min Conversion / Acquisition Time 510 nanoseconds per channel on OP4200
ADC Type 8 x Dual ADC
Input voltage range ± 20V
Bandwidth Small signal (-3 dB): 400 kHz
Accuracy ±10mV on the entire ±20V range
System noise max. 5Vrms
Recommended warm-up time 5 min.
Dimensions 6.60 cm x 12.50 cm (2.6” x 4.92”)
Operating temperature 0 to 50 ºC (32 to 122ºF)
Storage temperature -55 to 85ºC (-67 to 185ºF)
Relative humidity 10 to 90%, non condensing
Maximum altitude 2,000 m (6562 ft.)
