OP4200 User Manual OPAL-RT Technologies 31
OP4200 Hardware Specifications
OP4200 General Specifications
OP4230-1 SPECIFICATIONS
Product Name OP4230-1
Part Number 126-0157
Number of channels 16 single-ended
Resolution 16 bits
Default range ± 16 Volts
Maximum current 15 mA
Max. Sampling Frequency 1 MS/s
Min Conversion / Acquisition Time 1 μs per channel
DAC Type 8 x Dual DAC with 10 MBit/s Serial Output Transfer
Dc Transfer Characteristics
CMRR 100 dB
Dynamic Characteristics
Calibration Programmable gain and offset calibration for each D/A. Calibration factors are
stored in on-board non-volatile memory (EEPROM)
Maximum noise 20 mV peak-to-peak
Maximum offset ± 80 mV
Recommended warm-up time 5 min.
Calibration interval as required
Dimensions 6.60 cm x 12.50 cm (2.6” x 4.92”)
I/O connector 80-pin high speed header to carrier
Environmental
Operating temperature 10 to 40 °C
Storage temperature -55 to 85 °C
Relative humidity 10 to 90%, non condensing
Maximum altitude 2,000 m
