Vehicle care 227
Number Usage
46 Integrated chassis control
module
47 Headlight levelling device
48 Integrated chassis control
module
49 Interior rear view mirror
50 –
51 E-booster
52 Rear camera
53 Run/Crank
54 A/C control module
55 Rechargeable energy
storage system pump
56 –
57 Power electronics coolant
pump
58 Engine control module
59 Electric steering column
lock
Number Usage
60 HVAC electric heater
61 On-board charging module
62 Transmission range control
module 1
63 Electric cooling fan
64 Engine control module
65 Auxiliary heater pump
66 Powertrain relay
67 Drive unit controller
68 Rear window defogger
69 Second run/Crank relay
70 A/C control module
71 –
72 Transmission range control
module
73 Single power inverter
module
74 –
After having changed defective fuses,
close the fuse box cover and press
until it engages.
If the fuse box cover is not closed
correctly, malfunctions may occur.
Instrument panel fuse box
Instrument panel fuse box on the
left side end
The fuse box is located on the driver's
side behind a cover in the instrument
panel.
To open the compartment, compress
the locking tabs, fold cover down and
remove.
