Blank check
Remove HPA/DCO/AMA
Tableau encryption unlock
A job summary specific to that drive can also be viewed on the drive details screen,
with a link to view the filtered job history list for that drive. The Eject button for
each drive is located at the bottom-right side of the drive details screen.
3.3.5 Destination drives
Connect one or more drives to the TD4 destination (right) side: SATA (x2), PCIe,
and/or USB (x2). The associated user interface drive tile(s) will become active and
can be tapped to view detailed information about the drive and perform drive
specific actions. For destination drives, the available drive actions are as follows:
Browse filesystems
Blank check
Reconfigure (see “Reconfigure” on page 40 section for detailed information about
the destination drive Reconfigure function)
Tableau encryption unlock
A job summary specific to the drive can also be viewed on this screen, with a link to
view the filtered Job History list for that drive. The Eject button for each drive is
located at the bottom-right side of the drive details screen.
See “Duplicating” on page 53 and “Performing a logical image” on page 61 for
details on running Duplicate and Logical Image jobs.
3.3.6 Accessory drives
An Accessory USB port is available on the rear of TD4. This port can be used to
attach a USB drive to allow for exporting job logs or updating TD4 firmware. It can
also be used to attach a keyboard and/or mouse (wired or wireless).
Caution
The USB Accessory port on the rear of TD4 is not write-protected! Evidence
media should never be connected to this port.
When an Accessory USB drive is attached to TD4 and detected, a small drive tile will
appear just below the System Navigation Menu icon
in the top left of the user
interface.
3.3. Connecting drives
ISTD230100-UGD-EN-1
User Guide
29
