Chapter 6
Specifications and troubleshooting
6.1 Specifications
Connectors: Source Side
SATA/SAS One SATA/SAS (6 GBPS) signal connectors
Drive Power One 4-pin Molex Mini-Fit power connector for SATA/SAS
drive power
PCIe One PCIe (10 GBPS) adapter connector
USB One USB 3.2 Gen 1 (5 GBPS) Type-C connector
(USB 3.0 SuperSpeed equivalent)
Connectors: Destination Side
SATA Two SATA (6 GBPS) signal connectors
Drive Power Two 4-pin Molex Mini-Fit power connectors for SATA drive
power
PCIe One PCIe (10 Gbps) adapter connector
USB Two USB 3.2 Gen 2 (10 Gbps) Type-C connectors
Connectors: Miscellaneous
USB
(Rear Accessory Port)
One USB 3.2 Gen 1 (5 Gbps) Type-C connector
(USB 3.0 SuperSpeed equivalent)
DC Input One barrel connector for use with Tableau TP6 Power Supply
User Interface
LCD 4.95 in. graphic LCD (480 x 854 resolution) with capacitive
touchscreen
Power Button One on/off power button
Indicators
Power Indicator
(top left)
White LED (in power button) indicates TD4 is powered on
Status Indicator
(bottom right)
Multi-color LED indicates TD4 job status
Speaker Plays audio tones to indicate job completion/error status
Physical / Environment
ISTD230100-UGD-EN-1
User Guide
81
