to show in the filtered list. The filter criteria section of the screen can be expanded
and collapsed by tapping on the filter icon .
Note: There is an easy way to filter the Job History list to show only jobs
associated with a specific drive. To do so, tap on the desired drive tile from the
home screen. Scroll to the Jobs summary section at the bottom of the drive
details screen, and then tap on the View button. A list of only the jobs
associated with that drive will be shown.
To export the logs associated with jobs in the Job History list, tap on the Export
button at the bottom-left of the Job History screen. Select the desired filesystem and
then tap the Export button at the bottom-right corner of the browse window.
To delete the jobs (and their associated logs) that are shown in the Job History list,
tap the Delete button at the bottom-right of the Job History screen and follow the
prompt.
Note: For both exportation and deletion of jobs/logs, whatever jobs are shown
in the Job History list are the ones that will be acted upon. If there are no filters
in place, then all jobs/logs will be exported or deleted. If a filter is used to show
only a subset of the overall jobs list, then only those filtered jobs/logs will be
exported or deleted.
Up to 100 jobs can be stored on TD4. When that limit is hit, the start of any
subsequent jobs will require acknowledgement that the oldest job will be
automatically deleted. In order to avoid that inefficient job startup step, it is
recommended that job logs be exported and jobs be deleted at the end of each case.
2.3 Reading the status LEDs
On/Off indicator LED: The illuminated power switch is located in the top-left
corner of TD4, and it displays a white LED when the unit is on.
DC In LED: The TP6 power supply cable has a blue LED ring near the end of the
barrel connector that indicates the TD4 power supply is receiving adequate DC
input power.
Activity LED: The multi-color activity LED is located in the lower-right corner of
TD4. It is white when the unit is booting up, blinking white when a power issue is
detected, off when the unit is on but idle, blue when an operation is in progress,
blinking green when an operation completes successfully, and blinking red when an
operation fails.
