home screen. Scroll to the Jobs summary section at the bottom of the drive
details screen and then tap the View button. A list of only the jobs associated
with that drive will be shown. You can expand the filter in that view to see the
specific criteria that was used to filter the list.
To export the logs associated with jobs in the Job History list, tap on the Export
button at the bottom-left of the Job History screen. Select the desired filesystem and
folder and then tap the Export button at the bottom-right corner of the browse
window.
To delete the jobs that are shown in the Job History list, tap the Delete button at the
bottom-right of the Job History screen and follow the prompt.
Note: For both log exportation and job deletion, whatever jobs are shown in
the Job History list are the ones that will be acted upon. If there are no filters in
place, then all logs/jobs will be exported or deleted. If a filter is used to show
only a subset of the overall jobs list, then only those logs/jobs will be exported
or deleted.
Up to 100 jobs can be stored on TD4. When that limit is hit, the start of any
subsequent jobs will require acknowledgement that the oldest job will be
automatically deleted. To avoid that inefficient job startup step, it is recommended
that logs be exported and then jobs deleted at the end of each case.
See “Forensic logs” on page 70 for more information regarding TD4 forensic logs.
4.6 Viewing sources and destinations
To access the drive details screen for a source or destination, tap the desired drive
tile on the TD4 home screen. Drive tiles are shown on the left (source) and right
(destination) sides of the TD4 user interface. The drive details screen for a source
SATA drive is shown below.
4.6. Viewing sources and destinations
ISTD230100-UGD-EN-1
User Guide
37
