Chapter 5
Adapters
This chapter describes the drive adapters available for TD4, which extend imaging
capabilities in an easy to connect and use manner.
5.1 PCIe SSD adapters
Tableau PCIe SSD adapters enable the acquisition of PCIe based SSDs of various
types via the TD4 PCIE source port. The following adapters are available
individually or as part of an adapter kit:
PCIe card SSD adapter ‒ TDA7-1
PCIe m.2 SSD adapter ‒ TDA7-2
PCIe adapter for Apple SSDs 2013+ (through 2016) ‒ TDA7-3
PCIe u.2 SSD adapter cable ‒ TDA7-4
PCIe adapter for Apple SSDs 2016+ ‒ TDA7-7
Visit the Tableau product website to learn more about available Tableau PCIe SSD
adapters.
5.2 PCIe IDE adapter (TDA7‒5)
The PCIe IDE Adapter (TDA7-5) enables the acquisition of IDE drives via TD4's
PCIe source port. The IDE adapter kit (sold as an add-on to the TD4 kit) includes the
IDE power and signal cables used to connect the IDE drive to the adapter. The PCIe
cable used to connect the adapter to TD4 is included with the TD4 kit.
To use TDA7-5 with TD4, follow these steps:
1. With TD4 powered off, attach the TDA7-5 to TD4 by connecting it to the source
(left side) PCIe port using a Tableau PCIe cable (TC-PCIE-4 or TC-PCIE-8).
ISTD230100-UGD-EN-1
User Guide
77
